德國MICROSENS媒體轉換器
MICROSENS快速以太網媒體轉換器 MS410513-V2具有10/100Base-TX銅接口（例如交換機，路由器和網橋）的終端設備可以通過多模或單模光纖路由在較長距離上連接。MICROSENS快速以太網介質轉換器可實現雙絞線和光纖段在快速以太網中的直接耦合。根據應用領域，轉換器具有不同的光學參數。除了用于高達2公里傳輸的標準多模應用之外，還有單模版本可供15公里，40公里，80公里和125公里。段的鏈路狀態由轉換器進一步饋送，即光纖側的缺失鏈路在TP側不產生鏈路信號。電源連接有兩個選項。電源由外部電源（包含在傳送包中）實現。連接也可以通過成本效益的插孔（標準）或堅固的螺紋連接進行。
主要特征：
•具有成本效益和無中繼器的媒體轉換
•鏈接狀態的邏輯鏈接（鏈接）
•外部電源可選用堅固的螺紋連接
•金屬外殼，堅固的設計
| Article Number | Description | Connectors |
| MS410640-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1300 nm Multimode, 2 km, include power supply | 1 x RJ45 | |
| MS410641-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x ST |
| 1300 nm Multimode, 2 km, include power supply | 1 x RJ45 | |
| MS410646-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1300 nm Single mode, 40 km, include power supply | 1 x RJ45 | |
| MS410647-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x ST |
| 1300 nm Single mode, 40 km, include power supply | 1 x RJ45 | |
| MS410511-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1300 nm Multimode, 2 km, include screwable power connector | 1 x RJ45 | |
| MS410512-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x ST |
| 1300 nm Multimode, 2 km, include screwable power connector | 1 x RJ45 | |
| MS410513-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1300 nm Single mode, 15 km, include screwable power connector | 1 x RJ45 | |
| MS410518-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1550 nm Single mode, 80 km, include screwable power connector | 1 x RJ45 | |
| MS410519-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1550 nm Single mode, 125 km, include screwable power connector | 1 x RJ45 | |
| MS410523-V2 | Media Converter 100Base-FX/ 10/100Base-TX, | 2 x SC |
| 1300 nm Single mode, 40 km, include screwable power connector |
1 x RJ45 |
